TTDISC-1C

HAND-BUILT 700C ROAD CLINCHER 30MM DEPTH CARBON ROAD WHEELS

BTLOS 30mm aero carbon road wheel is designed to deliver outstanding climbing and acceleration while also using our U-shape to deliver aerodynamic performance at higher speeds.

Premium/Standard
BTLOS offers 2 constructions options for each of our rims. For cost-conscious buyers, we offer our Standard Construction which is available at lower costs and with a 1.5-year warranty for manufacturing defects. For buyers who are looking for the most advanced technology and performance, we offer Premium Construction. Premium Construction makes use of only Toray T700/T800 carbon and utilizes Smooth Inside Wall technology. Premium rims weight approximately 20g less (per rim) than their Standard counterparts and Premium rims are backed by a 3.5-year warranty against manufacturing defects.

Weight655800 kg

Categories: ,

Weight:
Extralight: 1257.8+/-25g (With Bitex & Sapim CX-Ray Spokes)
Material:
Extralight: Toray 40% T800 + 60% T700 Carbon Fiber
Premium: Toray 20% T800 + 80% T700 Carbon Fiber
Standard: Full Toray T700 Carbon Fiber
Nipples:
Sapim Brass (black) or Sapim alloy(black)
Spoke Pattern:
3X
Available Size:
650b, 29er
External Width:
26mm
Inner Width:
19mm
Depth:
30mm
Rim Type:
Clincher
Max Spoke Tension:
130kgf
Max Rider Weight:
Premium/Standard: 120kgs; Extralight: 95kgs
Max Tire Pressure:
120psi/ 8.27bar
Hole Count:
20H/24H, 24H/24H, 28H/28H
Weave:
UD/3K/12K
Finish:
Matte/Glossy
Tubeless Compatible:
Yes
Application:
Premium/Standard: Road, Cyclocross, Gravel;
Extralight: Road
Decal:
Customized
Tire Size:
1.9 - 2.3"
Asymmetric Offset:
2.6mm
ONE-PIECE MOLDING

Since the rims do not have the weaknesses associated with the various components of any of the different designs, they are continuously molded using techniques known as "one-piece molding". Because of this, the rims are perfectly symmetrical and evenly rolled.

COATING FREE

Due to high-quality carbon fiber and specially formulated epoxy (resin) along with state-of-the-art molding and manufacturing techniques.Just clear coating or none coating.See the finish info.

SPOKE HOLE ANGLES

We drill spoke hole angles to match or compliment the spoke angles created by the hub flange. Matching the spoke hole drilling angle in the rim to the spoke angle of the hub/hub flange allows the nipple to be better aligned with the spoke when the wheel is tensioned resulting in fewer broken spokes and nipples.

FLATNESS AND ROUNDNESS

Our molding and manufacturing techniques which allow us to control rim flatness to within 0.15mm and roundness to withing 0.2mm making it incredibly easy to build perfectly true, strong wheels.

HAND-BUILT

All wheels are 100% hand built to exacting standards by well trained wheel builders using only the best available components. All of our wheels are rigorously tested to guarantee accurate spoke tension and precise truing.
